Product Variants

No.	Item No.	Product Description	Bracket Length(mm)
No.	Item No.	Product Description	Bracket Length(mm)	Allowable load(Kn) is applied for a single load(F). If 2 or 3 loads are applied, below figures accordingly need to be doubled or tripled.
1	11127200	LR BR 21D-300 GEO	300	3.16	1.58	3.16	1.58	1.05
	11128200	LR BR 21D-500 GEO	500	1.90	0.95	1.90	0.95	0.63
	11129200	LR BR 21D-1000 GEO	1000	0.95	0.48	0.95	0.48	0.32
2	11121200	LR BR 41-300 GEO	300	3.12	1.56	3.12	1.56	1.04
	11122200	LR BR 41-500 GEO	500	1.86	0.93	1.86	0.93	0.62
	11123200	LR BR 41-1000 GEO	1000	0.93	0.47	0.93	0.47	0.31
3	11132200	LR BR 41D-300 GEO	300	9.20	4.60	9.20	4.60	3.07
	11133200	LR BR 41D-500 GEO	500	5.54	2.77	5.54	2.77	1.85
	11134200	LR BR 41D-1000 GEO	1000	2.78	1.39	2.78	1.39	0.93
4	11124200	LR BR 62-300 GEO	300	7.52	3.76	7.52	3.76	2.51
	11125200	LR BR 62-500 GEO	500	4.52	2.26	4.52	2.26	1.51
	11126200	LR BR 62-1000 GEO	1000	2.26	1.13	2.26	1.13	0.75
